• Available in wheel sizes: 25″ to 49″

  The EMH lock ring is designed to meet the need for a stronger and safer rim to suit the high pressures and increased loads of many earthmoving and industrial applications without compromising safety. This product can be produced utilizing MES and TSR components.

  By engineering a thicker, stronger lock ring RIMEX is able to offer improved strength and capacity in a RIMEX wheel with only minor design adjustments. The EMH lock ring is utilized with both MES and TSR series wheels.

  With the MES Series wheel, the only difference in the rim design is the lock ring and lock ring groove in the rim. The MES Series wheel assembly remains fully compatible with standard side rings and bead seat bands. An EMH style wheel allows for increased pressures and stresses without sacrificing safety concerns; as standard wheels are not safely rated for high air pressures or loads. Sizes available are 24” through 49” rim diameters.

• Available in wheel sizes: 25″ to 49″

  • Thicker and stronger lock ring provides improved strength and capacity.
  • Allows high air pressure with greater safety margin.
  • Improved tire stability and air retention for longer life and higher speeds.
  • Uniform tire and component fitment (greater o-ring seal).
  • Fully machined rim components.
•
•


•
