Lock Ring Support Stand

RIMEX Lock Ring Support Stand

Find a Location

  • Overview

    Designed with Safety in mind the Lock Ring Support Stand (LRSS) by RIMEX catches a one piece lock ring in the event it ‘springs off’ the wheel or rim during tire removal or mounting.

    The LRSS is supplied with adapters (4 per unit) to fit the most common 57” and 63” RIMEX gutter profiles. These adapters may also fit other manufacturers’ wheels, but are designed specifically for RIMEX products. For fitment to other manufacturers’ products or for less common gutter profiles, the supplied Adapter Gauges may be used to select the best fitting adapter available. Adapter sets are available to order from RIMEX.

  • Specifications

    Item number: 785-000-0227 for 45″ to 63″ wheels.

  • Features

    • Single design fits wheels and rims from 45” to 63” diameters.
    • Will not dislodge from wheel or rim base when catching lock ring.
    • Once installed, LRSS can remain in wheel/rim during tire change operations.
    • Acts as a support eliminating need for personnel to physically hold lock ring during installation.
    • Configurable adapters available for fitment to various wheel/rim designs.
    • Robust design weighing 19 lbs / 8.6 kg, 20% lighter than previous RIMEX LRSS models.
    • Manually telescoping height with finite adjustments.
    • Hand adjustable tension control.
